Characteristics:
• The 48V rack type batteries are widely used in different areas, it’s able to apply in fields of communication, new energy storage, vehicle power, electric power, computer backup supply etc.
• No memory effect, increase the batteries user life and performance
• Minimize replacement cost and reduce total cost of ownership
• Superior safety,eliminates the risk of explosion or combustion
• High continual power available
• High energy density-more energy with less weight and footprint
• Wide operating temperature . Predictable end of life due BMS controller
• Multiple communication interfaces: RS485, RS232,CAN
Smart BMS compatible motherboard with 30+ brand inverters . Such as Deye , Growatt, SMA, Solis, Sofar Solar, Sorotec, Luxpower etc
Parameters
SL100-48
SL150-48
SL180-48
SL200-48
SL240-48
Appearance
Metal case
Metal case
Metal case
Metal case
Metal case
Nominal Voltage
48V
48V
48V
48V
48V
Ah Capacity
100Ah
150Ah
180Ah
200Ah
240Ah
Pack Dimension
442*450*133mm
442*520*155mm
442*520*155mm
442*520*230mm
442*520*230mm
Energy Density
4800Wh
7200Wh
8640Wh
9600Wh
11520Wh
Weight
49Kg
65Kg
80.5kg
80.5kg
102 kg
Efficiency
>99.5%
>99.5%
>99.5%
>99.5%
>99.5%
Self Discharge/month
<3%
<3%
<3%
<3%
<3%
Design life(year)
>20
>20
>20
>20
>20
Parallel connection
<15
<15
<15
<15
<15
BMS Control
Yes
Yes
Yes
Yes
Yes
Protocol
RS-485
RS-485
RS-485
RS-485
RS-485
Datalogger record and store
in real time
in real time
in real time
in real time
in real time
Charge Voltage
48-54V
48-54V
48-54V
48-54V
48-54V
Working Tem. Range
-20~60℃
-20~60℃
-20~60℃
-20~60℃
-20~60℃
Working Humidity Range
5-95%
5-95%
5-95%
5-95%
5-95%
Max Continuous Discharging Current
100A
150A
180h
200h
240h
Max Continuous Charging Current
100A
150A
150A
150A
150A
Discharge output Inernal Resistance
<10mOhm
<10mOhm
<10mOhm
<10mOhm
<10mOhm
Running Power Consumption
<30mA
<30mA
<30mA
<30mA
<30mA
Static Power Consumption
10-50uA
100-50uA
100-50uA
100-50uA
100-50uA
BATTERY CELL SPECIFICATION
Cell Capacity
100Ah
150A
180A
200A
240A
Cell Charge Voltage
3.6V
3.6V
3.6V
3.6V
3.6V
Cell Max Continuous Discharge Current
300 or 3C
300 or 3C
300 or 3C
300 or 3C
300 or 3C
Cell Standard charge and discharge current
50 or 0.5C
50 or 0.5C
50 or 0.5C
50 or 0.5C
50 or 0.5C
Cycles life
6000 cycles
6000 cycles
6000 cycles
6000 cycles
6000 cycles
Case Materials
Matel
Matel
Matel
Matel
Matel
Case IP rating
IP56
IP56
IP56
IP56
IP56
Cell Type- Chemistry
LifePO4
LifePO4
LifePO4
LifePO4
LifePO4
Cell Type
Prismatic
Prismatic
Prismatic
Prismatic
Prismatic
Temperature Specification
Discharge Temp
-20~60℃
-20~60℃
-20~60℃
-20~60℃
-20~60℃
Charge Temp
0 to 45℃
0 to 45℃
0 to 45℃
0 to 45℃
0 to 45℃
Storage Temp
0 to 45℃
0 to 45℃
0 to 45℃
0 to 45℃
0 to 45℃
BMS High Temp Cut off
80C
80C
80C
80C
80C
BMS Reconnect Temp
50C
50C
50C
50C
50C
IP
40
40
40
40
40
